Description
The competition-ready Shimano XTR FC-M9200 crankset offers increased strength and reliability for world-class international racing and training. This ultra-lightweight version is optimized for maximum weight savings (XC) and utilizes iconic HOLLOWTECH II technology – a cold-forging process that achieves an excellent balance between high rigidity and light weight, while placing special emphasis on real-world impact resistance. Despite its light weight, it is stiff enough to provide masterful power transmission. Available in three different crank lengths (165 mm, 170 mm, and 175 mm), the crankset is compatible with all Shimano SM-CRM96 series chainrings.
- XC version focused on low weight
- Creates the right balance between reliable power transmission and low weight for top-level XC performance
- Crank with HOLLOWTECH II construction
- Compatible with all ultra-lightweight SM-CRM96 series chainrings (XTR)
- Supplied with a 24 mm axle and is compatible with threaded and press-fit bottom brackets
- XC-optimized 168 mm Q-factor
- 55 mm chainline
Shimano XTR FC-M9200 12-speed Crank without Chainring
Shimano XTR FC-M9200 12-speed Crank without Chainring
The Shimano XTR FC-M9200 1 x 12-speed XC crankset with 168 mm Q-factor and 55 mm chainline is made for uncompromising racing use and represents a further development of the legendary HOLLOWTECH II hollow forging process from SHIMANO.
Robust, intuitive and consistent: XTR FC-M9200 12-speed Crankset from Shimano
It is stiff enough for optimum power transmission, available in lengths of 165-175 mm and compatible with SM-CRM96 chainrings in all sizes. The FC-M9200 fulfils all the requirements of a lightweight and reliable cross-country crankset and the new XTR crankset offers increased strength and reliability for world-class racing and touring.
The crankset is offered in two application-specific designs - one for weight savings FC-M9200 and the other for more robustness FC-M9220 - and uses SHIMANO's proven hollow forging technology, which achieves a new balance between stiffness and weight while increasing impact resistance.
The pinnacle of MTB technology from SHIMANO. Developed for the demands of professional racing, the XTR is SHIMANO's lightest component group and convinces with robustness and podium-proven performance. Whether XC or Enduro, the new XTR series has been developed to withstand tough trails and demanding tracks. Every single component gives you a secure feeling from start to finish. The wireless, robust drivetrain can also withstand hard knocks on the trail. Thanks to the intuitive controls, you can concentrate fully on the ride. With the even more stable and powerful braking system, you can always ride at your own pace.
Features - Shimano XTR FC-M9200 1x12-speed Crank
- Lightweight: The crankarm and steel axle strike a balance between reliable power transfer and light weight for top-level XC performance
- Machined Chainring: The SM-CRM96 is Shimano’s lightest ever machined chainring (is not included!)
- HOLLOWTECH II: Shimano’s forging provides optimal weight, stiffness and rigidity for XC riding and racing
- Q Factor/Chainline: An XC-optimized Q Factor brings race-feel familiarity, while the 55mm chain line offers maximum frame compatibility
- Compatibility: M9200 cranks come standard with a 24mm spindle and are compatible with Shimano’s threaded and Press Fit bottom brackets
- FC-M9200 Q-Factor 168mm
- Chain line 55mm
- O.L.D 131mm / 141mm / 142mm / 148mm
- Compatibility 1 x 12-speed with CS-M9200 cassettes 9-45 and 10-51
- Mounting system Direct mount (Lighter and stiffer design & easy exchangeable chainring by direct mount and one key release)
- Chainring SM-CRM96 Available in different gradations (28-30-32-34-36-38) - Chainring is not included!
Product features
- Use: MTB Cross-Country
- Group: XTR M9200
- Model: FC-M9200
- Gradation: Chainring is not included!
- Q-Factor: 168mm
- Threaded BB shell width: 68 / 73mm
- Gear rear: 12-speed
- Construction: Hollowtech II
- Compatible Chain: 12-speed HG
- O.L.D: 131mm / 141mm / 142mm / 148mm
- Chain line: 55mm
Crank arm length (choose variant)
- 165mm
- 170mm
- 175mm
Specifications
- Brand
- Shimano
Product features
- Model
- FC-M9200
- Gradation
- Chainring is not included!
- Q-Factor
- 168mm
